Main Technical Parameters
|
Voltage of Power Supply
|
Domestic Standard: 220V 50Hz±1Hz～380V 50Hz±1Hz 1Hz
|
|
Exported product can be customized: 110V～480V (50Hz～60Hz)
|
|
Output pushing force
|
6400～64000N
|
|
Effective travel
|
10mm~150mm
|
|
Input signal
|
DC4～20mA, switching signal (relay signal), pulse signals, and others
|
|
Output signals
|
DC4～20mA (Load resistance is 500Ω or less)
|
|
Control accuracy
|
Basic error:±1%; Return difference≤1%; Dead area≤1%
|
|
Adjustable range of working travel
|
"zero point"±10%; "travel"35%～110%
|
|
Display mode
|
LED digital code
|
|
Level of protection
|
IP55～IP68
|
|
|
External wiring
The shielded cable shall be adopted for input and output signals. One cable cannot be used for power cord and signal line together
|
Power cable
|
S=1.5mm2~4mm2
|
|
Signal cable
|
S=1.5mm2
|
|
Cable entry
|
PG16 PF3/4″
|
Environmental Conditions
|
Environmental temperature
|
Without space heater -10℃～70℃
|
|
With space heater -35℃～60℃
|
|
Relative Humidity
|
≤95%
|
|
Environmental gas
|
No corrosive gas
|
|
Mechanical vibration
|
XY210G. 0.2～34Hz. 30minutes
|
|
